•Wheel Size: 27.5", 29"
•Weight: 1730g-1750g
•Offset: 37/44OS (27.5"), 44OS (29'')
•Ride Height: 27.5:
-110mm = 502 a2c
-120mm = 512 a2c
-130mm = 522 a2c
-140mm = 532 a2c
-150mm = 542 a2c
29:
-110mm = 522 a2c
-120mm = 532 a2c
-130mm = 542 a2c
-140mm = 552 a2c
-150mm= 562 a2c
•Spring: Dorado Air with Infinite Rate Tune (IRT)
•Compression Damping: Sealed Cartridge TPC+ with Hydraulic Bottom Out (HBO)
•Rebound Damping: Sealed Damper TPC
•Adjustments: Air, IRT, Rebound, HS, and LS Compression
•Steerer: 1.5" Tapered
•Crown: Forged Aluminum, Hollow Bore
•Leg Diameter: 34mm
•Leg Material: 7000 Series Butted Wall Aluminum
•Brake: Post Mount 160mm
•Axle: 15mm x 110mm Hexlock
•Max Tire Size: 67mm
•Options: Fender Kit, TSR, Hexlock SL2
•E-Bike Compatible: Yes
